ATENG 10772 — Biomedical Magnetotherapy Unit
Bench-top unit.
Anodized aluminum frame and panels made of painted steel.
Main metallic elements made of stainless steel.
Diagram in the front panel with distribution of the elements similar to the real one.
- Magnetotherapy instrument:
- Application of Magnetotherapy:
- Frequency of treatment: 1 - 100 Hz.
- Maximum induction: 100 G ± 20 %.
- Available outputs: 2.
Two buttons to select the frequency and the intensity of the treahtment.
ATENG 10772 detail
LCD display for control and visualization of the magnetic field provided.
- Gauss meter:
- Range: 20 - 200 ± 0.1 % µT.
- Bandwidth: 30 - 300 ± 60 Hz.
- Mode selector: off, Tesla and Gauss measurements.
- Magnetotherapy applicator:
Two solenoid coils of 15 cm.
Solenoid coil of 30 cm.
- Human bone model:
Piezoelectric sensors.
Magnetic field tester.
Cables and accessories, for normal operation.
