Bitumen Penetrometer

Used to determine the consistency of a bituminous sample under fixed conditions of load, time and temperature. The penetration is expressed in distance of tenths of millimeters vertically penetrated by a standard needle.

STANDARDS COMPLIANCE :

• COMPLIED AS PER EN 1426, ASTM D5, AASHTO T49

Supply / Components :

• The Bitumen Penetrometer is supplied with stop and release push button, automatic zero timer set, penetration needle, transfer dish and beaker of penetration tips 55x35 mm dia.

Optional Accessories :

• Mirror with articulated holder is available to make easy the surface contact between the needle and the sample and should be ordered separately.
• The other accessories should be ordered separately.

Dimensions (cm) :

• 20x30x50

Weight (kg) :

• 10

Power Supply :

• 220 V, 50-60 Hz, 1 ph

Dimensions (cm) :

• Moisture content tin - 55 x 3,5
• Moisture content tin - 7 x 4,5

Weight (kg) :

• Penetration Needle - 0,0025
• Moisture content tin - 0,02
• Moisture content tin - 0,03

Standards :

• Penetration Needle - EN 1426, ASTM D5, AASHTO T49
• One-Quarter Scale Cone and Shaft for Lubricating Grease - ASTM D1403 & ASTM D1831
• One-Half Scale Cone and Shaft for Lubricating Grease - ASTM D1403 & ASTM D1831
• Brass Penetrometer Cone for Lubricating Grease and Petrolatum - ASTM D217 & ASTM D937

• Penetration is measured with digital gauge 0,01 mm resolution.
