Black Box Apparatus

EXPERIMENT: IDENTIFICATION OF UNKNOWN COMPONENTS BY OBSERVING THEIR AC RESPONSE & DETERMINATION OF THE VALUES OF THE COMPONENTS (INDUCTOR, CAPACITOR & RESISTOR)

EXPERIMENT SETUP CONSISTS OF:

• Black Box Kit – With digital voltmeter of 0–2 V, built-in unknown components housing a capacitor, inductor and resistor, connecting wires and manual, cabinet made of acrylic
• Signal Generator – Microcontroller-based digital signal generator producing frequency up to 1 MHz, 20 V p-p output in sine, square, triangular and pulse waveforms, digital display for frequency and waveform display

Designed and manufactured by Atico Export to meet the practical demands of modern laboratories.
