Brinell Hardness Testing Unit Deluxe

The Brinell Hardness Testing Unit, allows Brinell hardness measurement on different materials.

ATENG 12226 — Brinell Hardness Testing Unit

• Brinell Hardness Testing Unit 30 kN:
  It can work with round, flat or irregular shape test pieces.
• Response time control: adjustable between 5 and 60 seconds.
• Measurement range: 8-650HBW.
  The test load is applied by an electrical motor.
• Applied test force: 612.9 N (62.5 Kgf) – 980 N (100 Kgf), 1226 N (125 Kgf) – 1839 N (187.5 Kgf) –
  2452N (250 Kgf) – 4903 N (500 Kgf) – 7355 N (750 Kgf) – 9807 N (1000 Kgf) – 29420 N (3000 Kgf).
• Maximum height of the test piece: 220 mm.
• Throat depth (distance between the central point of the indenter and the hardness tester body): 135
  mm.
  ATENG 12226 detail
• Small test piece holder plate: 60 mm diameter.
• Large test piece holder plate: 200 mm diameter.
• “V” shape test piece holder plate: 80 mm diameter.
• Indenters:
• Steel ball of 2.5 mm diameter.
• Steel ball of 5 mm diameter.
• Steel ball of 10 mm diameter.
  Four additional balls of each size.
• Two testing blocks:
  HBW/3000/10 (150 ~ 250).
  HBW/750/5 (150 ~ 250).
• Portable microscope to read the imprints:
• Amplification: 20 X. Minimum division value of the micrometer wheel: 0.005 mm. Reading field effective range: 6 mm.
  Spare fuse.
