BVS4000 Brookfield Viscosity Air Bath System for Oil Fuel and Petroleum Testing Instruments

The Low-Temperature Lubricant Sample Conditioning Cabinet prepares lubricant samples for dynamic viscosity determination using a rotational viscometer. It is suitable for gear oils, automatic transmission fluids, hydraulic oils, and other petroleum lubricants requiring low-temperature, low-shear-rate viscosity testing. The mechanically refrigerated cabinet features digital temperature control and a built-in turntable that rotates samples at 4 RPM according to applicable specifications. The cooling system maintains cabinet temperature stability within ±0.1°C at temperatures as low as -50°C. Digital temperature readings are displayed on the front panel. The cabinet accommodates sixteen sample cells with cell carriers and includes an insulated cover. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for low-temperature lubricant viscosity testing applications.

Testing Capacity:

• 16 samples
• Sample cells with carriers

Temperature Range:

• +10°C to -50°C

Temperature Control:

• Mechanically refrigerated cooling system
• Digital temperature indication and control
• Temperature stability: ±0.1°C

Sample Rotation:

• Turntable speed: 4 RPM

Construction and Features:

• Mechanically refrigerated cold cabinet
• Built-in rotating turntable
• Front-panel digital temperature display
• Insulated cover

Dimensions (L × W × H):

• 36 × 28 × 43 inches (91 × 71 × 109 cm)

Net Weight:

• 450 lbs (205 kg)
