Calibration of Voltmeter and Ammeter Using Potentiometer

Calibration of Voltmeter and Ammeter Using Potentiometer setup is designed to study the operation and calibration of a potentiometer, voltmeter, and ammeter. The complete setup consists of a training board, potentiometer, and calibration unit.

The calibration unit includes a voltmeter and an ammeter that can be calibrated using the potentiometer. A potentiometer is an instrument used to measure an unknown voltage by comparing it with a known voltage and provides a high degree of measurement accuracy.

The setup provides a suitable platform for laboratory experiments, education, training, and skill development.

Physics Lab Experiments Setup from Atico Exports.

Regulated Power Supply :

• 2 V / 100 mA
• Designed to Operate the Potentiometer

Electronic Standard Cell :

• Precisely Calibrated
• Voltage: 1.0186 V

Voltage Source :

• Regulated Power Supply
• Range: 0 to 2 V
• Current: 1 A

Galvanometer :

• Provided for Null Balance

Voltmeter :

• Range: 0 to 2 V
• Provided for Voltage Comparison and Measurement

Ammeter :

• Range: 0 to 1 A
• Provided for Current Measurement

Resistance :

• Standard Resistance
• Unknown Resistance
• Provided for Performing the Experiment

Usage / Application :

• Laboratory
