Calibration station

The calibration station is used in the investigation of the transmission behaviour of electrical and pneumatic control loop components. Electrical and pneumatic signals can be generated to effect actuation of the individual control loop components. A precision measuring technique facilitates the recording of the output signals from the control loop components. Learn about Calibration station suppliers for optimal educational outcomes.. The supply of auxiliary power necessary for many control loop components is also provided.

• investigation of transmission behaviour and calibration of electronic and pneumatic control loop components
• sending and measuring pneumatic and electrical signals
• 3 pressure regulators with manometers
• adjustable power supply unit as DC voltage source
• 2 switchable AC voltage sources with differing voltages
• 3 digital pressure gauges with differing measuring ranges
• 2 adjustable potentiometers
• freely configurable industrial controller
• digital voltmeter
• digital ammeter
• 3-channel line recorder with freely selectable measuring ranges
• separate high-grade universal calibrator for voltage, current, temperature and resistance
