Capacitor in Series & Parallel With Auto Transformer 2Amp for Physics Lab Experiments

LCR Circuit Experiment Setup is designed to plot frequency versus current characteristics of an LCR circuit when connected in series or parallel.

Physics Lab Experiments Setup from Atico Exports.

Experiment :

• To Plot Frequency vs. Current Characteristics of an LCR Circuit Connected in Series or Parallel

Resistances :

• 3 Resistances

Capacitors :

• 3 Capacitors

Inductance :

• 1 Inductance

Connections :

• Components Connected Internally
• Connections Provided on Sockets

AC Moving Coil Meters :

• 2 Meters
• Provided for Measuring Voltage and Current

Built-in Sine Wave Oscillator :

• Frequency Range: 100 Hz to 100 kHz
