Carbonator, Filling and Capping

The latest in high accuracy carbonation and filling technology. Can carbonate premixed products or water and syrup in post mix configuration. Fills soft and alcoholic beverages into PET, bioplastic, glass and cans with screw capping, crown capping and integral can seamer. Learn about Carbonator, Filling and Capping manufacturers for optimal educational outcomes..

The latest in high accuracy carbonation and filling technology. Can carbonate premixed products or water and syrup in post mix configuration. Fills soft and alcoholic beverages into PET, bioplastic, glass and cans with screw capping, crown capping and integral can seamer. Learn about Carbonator, Filling and Capping for educational labs for optimal educational outcomes.. Features reduced minimum batch volumes, ability to carbonate highly foaming products and internally mounted chiller to reduce space requirement.

• Gas content: 0-12 g/l
• Vessel capacity: 15 litres or 30 litres working capacity
• Capping methods: Screw, Crown, Can Lid, Rip-Cap
• Gases: CO₂, N₂ or any safe, non-flammable alternatives or mixture
• Contact surfaces: 316L stainless steel, food-grade silicone, PTFE, borosilicate glass and other food-safe materials
• Operation methods: Batch or semi-continuous
• Minimum batch volume: 1 – 3 litres (depending on vessel volume)
• Maximum vessel pressure: 4 bar

• Accurate carbonation levels in excess of 12g/l (° 0.1g/l)
• Cans, PET and glass bottle filling
• Screw, crown and Rip-cap capping
• Can seaming
• CO₂ recycling for environmentally friendly processing
• Deaeration and vessel purging
• Vacuum system compatible with high-foaming products
• In-bottle pressure measurement
• Pre-mixing and post-mixing capability
• Syrup dosing into the bottle
• ArmBUS control system with 32 process recipes
• Full data capture through ArmBUS data viewer (exportable to Excel)
• Reduced bottle movement increases accuracy and reliability
• On-board high-efficiency chiller reduces laboratory space requirements
• Removable side panels and IP65 electrical cabinet for easy maintenance
• Can operate as standalone unit or with continuous feed vessel
• No need for external chiller or ice water supply
