CB Transceiver Trainer

The trainer consists of CB unit which has been mounted in a special chassis with all key internal parts exposed
All controls are functional just as on an actual CB and test points are available for the student to make measurements and tests directly without opening the case

• The fault is activated by touching an electronic switch with a special teaching probe
• Faults may be visualized by use of the optional LED fault display board which features a schematic of the circuit block diagram silk screened onto the display panel that incorporates LEDs to show the location of the faults
• LEDs may be switched off, thereby not allowing the student to know where the fault is
