CBR & Marshall & Uniaxial Testing Machine

The device is composed of a robust and compact two column frame with adjustable upper cross beam driven by an electromechanical ram.
Two models are available as 50 kN and 100 kN capacity.

Application :

• CBR & Marshall & Uniaxial Testing Machine is used to make CBR, Marshall and Uniaxial Unconfined Compressive Tests.

Specifications :

• The testing speed can be set between 0.001 mm/min to 51 mm/min.
• The speed setting of the loading plate is controlled from the digital readout unit.
• For safety, the up and down travel of the lower platen is limited the use of limit switches.
• The measuring system consists of a 50 kN or 100 kN capacity load cell according to capacity of frame fitted to the upper cross beam to read stability values and the 25 mm Displacement Sensor fitted to the column.

Standard Supply :

• Supplied complete with LCD CBR & Marshall & Uniaxial Control Unit, 50 kN or 100 kN capacity Load Cell according to capacity of frame, 25 ° 0.01 mm Linear potentiometric displacement transducer with holder.

Test Speed :

• 0.001 – 51 mm/min

Capacity (kN) :

• 50

Dimensions (cm) :

• 47°70°110

Weight (kg) :

• 100

Power Supply :

• 220 V, 50–60 Hz, 1 ph

Optional Accessories :

• The other Test Accessories should be ordered separately according to the test. Compression Platens with ball seating assembly for Uniaxial Tests, Penetration Piston for CBR Tests and Breaking Head for Marshall Tests should be ordered separately.
