CBR TEST MACHINE WITH LOAD RING

The device is composed of a robust and compact two column frame with adjustable upper cross beam.
The CBR Test Machine designed to load the penetration piston into the soil sample at constant rate to measure the applied load and piston penetration at predetermined intervals. The frame has 50 kN capacity.

Standards Compliance :

• Complied as per EN 13286-4, BS 1377-4, ASTM D1883, AASHTO T193, NF P94-078, UNI CNR 10009

Application :

• CBR Test Machine is designed for performing laboratory evaluation of the CBR value of highway sub-bases and sub-grade and determination of the strength of cohesive materials.

Test Speeds :

• Two test speeds can be chosen by using speed buttons on the device as 1.0 mm/min for BS and 1.27 mm/min for ASTM/EN/AASHTO Tests.

Safety :

• For safety, the up and down travel of lower platen is limited the use of limit switches.

Measuring System :

• The measuring system consists of a 50 kN capacity Load Ring fitted to the upper cross beam to read stability values and the 30 ° 0.01 mm Analog Dial Indicator fitted to the column.

Supplied Complete With :

• Supplied complete with 50 kN Load Ring with 0.01 mm resolution Analog Dial gauge, 30 ° 0.01 mm Analog Dial Indicator and CBR Penetration Piston.

Dimensions (cm) :

• 47°61°115

Weight (kg) :

• 80
