Cement Flow Table - Motorized

Standards Compliance :

• COMPLIED AS PER EN 459-2, EN 1015-3, ASTM C230

Application :

• Used for determining the consistency of mortar, lime, and cement specimens.

Available Models :

• Manual and motorized models are available.

Operation :

• The hand-operated model is fitted with a hand wheel.
• The motor-operated model is driven by a motor speed reducer through a mechanical coupling at a rate of 1 revolution per second.
• The number of drops is preset on a counter and the machine stops automatically at the end of the cycle.

EN Model Specifications :

• In EN model, the table is manufactured from stainless steel °300 mm.
• The cone is made of brass with dimensions: °100 mm base ° °70 mm top ° 60 mm height.

ASTM Model Specifications :

• In ASTM model, the table is manufactured from bronze °254 mm.
• The cone is made of brass with dimensions: °100 mm base ° °70 mm top ° 50 mm height.

Table Dia. (mm) :

• AECE2156 - °300
• AECE2157 - °254

Drop Height (mm) :

• AECE2156 - 10
• AECE2157 - 12.7

Dimensions (cm) :

• AECE2156 - 260 ° 260 ° 27
• AECE2157 - 260 ° 260 ° 27

Weight (kg) :

• AECE2156 - 13
• AECE2157 - 13

Supply Includes :

• Both models are supplied complete with flow mould and tamper.
