Cement Mortar Flexural Testing Jig

Usage :

• Suitable for laboratory experiment

Frame :

• Fitted with roller beaters (accordance to EN 196-1)

System :

• Robust Frame Structure, fitted with an upper bearer that moves vertically supported by springs. One of the two lower bearer can tilt horizontally

Flexural Jig :

• Designed for testing of Cement Prism (Size : 40 x 40 x 160 mm)

Distance between Two Bearers :

• 100 mm

Lower Bearer (Supporting Roller) :

• Length : between 45-50 mm, Dia. : 10 (+- 0.5) mm

Upper Bearer :

• Length : between 45-50 mm, Dia. : 10 (+- 0.5) mm

Total Height :

• 188 mm
