Cement Permeameter with DAQ Testing by ATICO EXPORT

The cement permeameter is designed to measure the permeability of cement core specimens one inch in diameter and one inch in length. A core specimen is placed into a core sleeve, which is then inserted into the modified Hassler style test cell. Nitrogen at a constant flow rate is forced through the core and the differential pressure across the core is measured. The flow rate is measured with calibrated flowmeters. Viscosity is determined using nitrogen property tables, and these variables are incorporated into Darcy’s law to calculate sample permeability.

Compressed air :

• 100 PSI (689.5 kPa)

Gas pressure :

• Standard air, carbon dioxide, nitrogen or oxygen up to 500 PSI (3.5 MPa)

Electrical :

• 115 Volt, 50 or 60 Hz
• 230 Volt, 50 or 60 Hz

• Modified Hassler cell accommodates cores of 1" length and 1" diameter
• Instrumentation gauge displays driving pressure
• All Hassler components fabricated from 316 stainless steel
• Nitrogen test fluid
• Cement mold included
