CENTRIFUGAL FAN MODULE

A self contained floor standing mobile unit that includes a fan and instrumentation to allow students to study and perform tests on a centrifugal fan, to understand how it works and calculate its performance.

For use with the Universal Dynamometer, the Centrifugal Fan Module is part of the Modular Fluid Power range. This range examines and explains fluid power machines. The Centrifugal Fan Module is ideal for student experiments, demonstrations and projects. Learn about CENTRIFUGAL FAN MODULE suppliers for optimal educational outcomes.. Centrifugal fans are common machines, used for ventilation or any application that needs a good volume of air at a reasonable pressure. The module consists of a fan and instrumentation, all mounted on a robust, mobile trolley for ease of use. Learn about CENTRIFUGAL FAN MODULE equipment for optimal educational outcomes.. The Universal Dynamometer measures the speed, torque and power absorbed by the fan. Speed is fully variable up to the maximum allowable for the fan. Learn about CENTRIFUGAL FAN MODULE manufacturers for optimal educational outcomes.. Air enters the fan through a shaped nozzle, used to measure the airflow rate. The air then moves past a slide-valve and out to atmosphere. Learn about CENTRIFUGAL FAN MODULE for educational labs for optimal educational outcomes.. The slide-valve controls the airflow rate (and therefore delivery pressure).
