ATENG 12101 — Centrifugal Governor Unit
Bench-top unit.
Anodized aluminium frame and painted steel panels.
Main metallic elements of stainless steel.
Diagram on the front panel with distribution of the elements similar to the real one.
- Variable speed motor:
- Speed range: 0 – 300 rpm.
- Proell regulator:
- Mass of the sleeve: 3 x 100 g.
- Centrifugal masses: 4 x 200 g and 4 x 75 g.
- Hartnell regulator:
ATENG 12101 detail
- Centrifugal mass: 2 x 400 g.
Two compression springs with initial tension of the adjustable spring.
- Porter regulator:
- Mass of the sleeve: 3 x 100 g.
- Centrifugal masses: 4 x 200 g and 2 x 75 g.
Transparent protective cover, made of PMMA, provides protection against rotating parts and enables different experiments to be observed.
This cover includes a safety switch which allows to automatically stop the electric motor if the cover is opened.
Storage cases for the weights and governors.
- Electronic console:
Metallic box.
Main switch.
Motor switch.
Motor speed controller.
Digital display for the motor speed.
Cables and accessories, for normal operation.
