Chemical Reactors

The Chemical Reactors, for the study and comparison of different types of chemical reactors in an easy and simple way and thus allowing, on a small scale, to carry out the necessary studies and practices to understand the operation of the reactors.

ATENG 10922 — Chemical Reactors

• ATENG 10924. Base and Service Unit for ATENG 10922:
  Bench-top unit.
  Anodized aluminum frame and panels made of painted steel.
  Main metallic elements made of stainless steel.
  Diagram in the front panel with distribution of the elements similar to the real one.
  This unit is common for the required elements (at least one) (Not included).
  Accommodation and exchange system of the reactors, quick and easy to handle.
  It supplies all the services for the operation of each reactor.
  Safety, easy and quick connections.
  All elements of this unit are chemically resistant.
• The “ATENG 10924” unit mainly consists of:
  Two peristaltic dosing pumps, with variable speed. Flow rate up to 3 l/h (unit standard
  disposition). With another disposition, they could reach a flow rate up to 10 l/h.
• Thermostatic bath, capacity: 6 l. Temperature control of hot water in order to maintain
  the reactor temperature.
  Pump of 3 l/min, to impel the thermostatization water from the bath to the reactor.
• Two tanks for the reagents, capacity: 1 l each one, made of Pyrex glass.
  The control of the reaction is carried out by a conductivity sensor, which allows the ATENG 10924 detail
  reaction evolution parameterization in real time.
  Three “J” type temperature sensors, one to know the thermostatic bath temperature in a continuous
  way and two sensors to know the water temperature of the thermostatic bath water inlet and outlet.
  Quick connectors with shutoff valve that enable an easy coupling of the Service Unit to the chosen
  reactor.
• Electronic console:
  Metallic box.
  Temperature sensors connections.
  Digital display for temperature sensors.
  Selector for temperature sensors.
  Peristaltic pumps controllers and switches.
  Water pump switch.
  Stirrer switches.
  Heating element controller.
  Main switch.
  Cables and accessories, for normal operation.
