Class II Biosafety Cabinet Type B2 450 Millimeter Opening

Class II Biosafety Cabinet Type B2 is designed to provide reliable personnel, product, and environmental protection for handling hazardous biological materials. It features dual ULPA filters with 99.9995% filtration efficiency at 0.12 µm, ensuring superior air cleanliness and contamination control. The cabinet is equipped with a motorized anti-UV laminated glass front window, a microprocessor-based control system, and an LCD display for real-time monitoring of airflow, UV status, temperature, and humidity. Manufactured by Atico Export India.

• Clinical laboratories
• Diagnostic laboratories
• Microbiology laboratories
• Virology laboratories
• Pharmaceutical laboratories
• Biotechnology research and development
• Hospitals and healthcare facilities
• Universities and research institutions
• Public health laboratories
• Government laboratories

Maximum Opening :

• 420 mm (17 inches)

Tested Opening :

• Safety height: 200 mm (8 inches)

Work Surface Height :

• 750 mm (customizable)

Air Inflow Velocity :

• 0.53 ± 0.025 m/s

Air Downflow Velocity :

• 0.33 ± 0.025 m/s

ULPA Filters :

• Two
• 99.9995% efficiency at 0.12 µm
• Filter life indicator included

Front Window :

• Motorized, two-layer laminated toughened anti-UV glass (6 mm)

Noise Level :

• Less than 67 dB

UV Lamp :

• 30 W × 1

UV Lamp Mode :

• UV timer
• UV life indicator
• Emission wavelength: 253.7 nm

Illuminating Lamp :

• LED lamp

Lamp Power :

• 12 W × 2

Illumination :

• Greater than 1000 lux

Power Consumption :

• 850 W

Waterproof Sockets :

• Two
• Total load: 500 W

Control System :

• Microprocessor

Airflow System :

• 0% air recirculation
• 100% air exhaust

Alarm Functions :

• Abnormal airflow
• Filter replacement reminder
• Unsafe window height
• High pressure alarm

Exhaust Duct :

• 4 meters PVC duct
• Diameter: 300 mm

Work Zone Material :

• 304 stainless steel

Main Body Material :

• Cold-rolled steel with anti-bacterial powder coating

Caster :

• Footmaster caster

Power Supply :

• 220 V ±10%, 50 Hz

Main Body Dimensions :

• 1460 × 1000 × 1820 mm

Exhaust Blower Dimensions :

• 970 × 810 × 630 mm

External Dimensions (W × D × H) :

• 1300 × 750 × 2250 mm

Internal Dimensions (W × D × H) :

• 1150 × 600 × 660 mm

Weight :

• 280 kg

Standard Accessories :

• Illuminating lamp × 1
• UV lamp × 2
• Base stand × 1
• Remote control × 1
• Foot switch × 1
• Exhaust blower × 1
• Exhaust duct × 1
• Drain valve × 1
• Sockets × 2
• Pipe strap × 2
• Water and gas tap × 1

Optional Accessories :

• Electric height-adjustable base stand

• Motorized front window
• Auto-adjusting airspeed
• Power failure memory recovery
• Remote control access
• Redundant safety alarm system
• Foot switch control
