Climatic Chambers

• Inner chamber made of stainless steel; outer body electrostatically painted steel.
• Shelves removable and height-adjustable; adjustable feet.
• Double tempered glass door allows observation without disturbing chamber conditions.
• High-density polyurethane insulation between inner and outer walls.
• Humidity supplied via humidity generator and read by humidity sensor.
• Temperature controlled with PID system.
• Touch-screen 12.8– ° 6.4– LCD controller.
• Microprocessor- controlled system with data storage.
• 10 programmable test programs.
• Gas used for cooling does not include CFCs.

Standards Compliance :

• Complied as per EN 1367-1, EN 12390-2, EN 12390-9, EN 196-1

Application :

• Designed for research and quality control laboratories to perform:
• Cold / hot temperature tests
• Controlled humidity conditions
• Freeze–thaw cycles
• Aging and durability tests

Optional :

• Lighting lamp optional.

Capacity (lt) :

• AECE2033/A - 120
• AECE2033/B - 250
• AECE2033/C - 500

Working Temp. Range (without light) :

• AECE2033/A - –10 °C to +60 °C
• AECE2033/B - –10 °C to +60 °C
• AECE2033/C - –10 °C to +60 °C

Working Temp. Range (with light) :

• AECE2033/A - 0 °C to +60 °C
• AECE2033/B - 0 °C to +60 °C
• AECE2033/C - 0 °C to +60 °C

Humidity Range :

• AECE2033/A - 20–95 %RH
• AECE2033/B - 20–95 %RH
• AECE2033/C - 20–95 %RH

Temp./Humidity Sensitivity :

• AECE2033/A - °0.1 °C / °1 %RH
• AECE2033/B - °0.1 °C / °1 %RH
• AECE2033/C - °0.1 °C / °1 %RH

Lighting :

• AECE2033/A - Optional
• AECE2033/B - Optional
• AECE2033/C - Optional
