Color Television Trainer

The TV is mounted on an attractive chassis which allows the main printed circuit board to be exposed for ease of work
The circuit board features a plexiglass cover which has openings for access to all test points so as to allow insertion of probes while protecting the student and the circuit board
The CRT is mounted in its original case which has been modified so as to allow the rear of the tube to be easily accessible for student work
The trainer allows access to all the factory recommended key points for the taking of measurements, analysis and adjustments, the results of which are readily observable

These trainers are specifically created to teach television operation, theory, repair and servicing

• Special attention is given to fault diagnosis so as to facilitate the teaching of troubleshooting techniques
• The CRT, a unique fault insertion system is built into the trainer for student instruction purposes
• The system features a schematic block diagram silk screened onto an integral fault board that utilizes LEDs to indicate the nature and location of the fault
• The fault is activated by touching an electronic switch
• The faults may be visualized by use of the LED lights or the LEDs may be switched off, thereby not allowing the student to know where the fault is
