Colorimetric Analysis Physics Lab Experiments Instrument

This colorimetric instrument is designed for luminous body colorimetric measurements and offers a practical and cost-effective solution for color analysis applications. It is suitable for use in universities, laboratories, and research institutions involved in physical optics, vision science, physiology, psychology, and other related scientific disciplines. The instrument enables accurate color measurement and analysis for a wide range of educational and research applications.

Physics Lab Experiments from Atico Exports.

Experimental Principle and Content

• Study of luminous body colorimetric measurement techniques.
• Analysis of color characteristics and spectral distribution.
• Investigation of color perception and measurement principles.
• Applications in physical optics, vision science, physiology, and psychology.
• Experimental evaluation of color parameters using spectral analysis methods.

Grating :

• 1200 Lines/mm

Wavelength Accuracy :

• ±0.4 nm

Wavelength Repeatability :

• ≤ 0.2 nm

Focal Length :

• 302.5 mm

Relative Aperture :

• D/F = 1/7

Scan Range :

• 380 nm – 780 nm

Other Parameters :

• Stray Light ≤ 10⁻³
• Resolution ≤ 0.06 nm
