Compacting Factor Apparatus

The apparatus consists of two conical hoppers mounted on a cylinder.
Each hopper has a hinged flange with quick release mechanism and everything is mounted on a rigid steel stand.
The compacting factor is the ratio between the weight of the partially compacted concrete and the weight of the fully compacted concrete.

Standards Compliance :

• Complied as per BS 5075, BS 1881:103

Application :

• The Compacting Factor Apparatus is used to determine the compaction factor of concrete with low, medium and high workability.

Dimensions (cm) :

• 30 ° 40 ° 130

Weight (kg) :

• 40
