Complete Holographic Physics Lab Experiment Setup

Overview

This experimental system is designed for the study of optical holography, enabling the recording and reconstruction of three-dimensional images using the principles of interference and diffraction. Holographic techniques allow both the amplitude and phase information of light waves to be captured, making them an important tool in optical imaging, information storage, and photonics research.

This physics laboratory experiment system, manufactured by Atico Exports, provides a comprehensive platform for studying geometric optics, wave optics, interference, diffraction, holography, polarization, and information optics through hands-on experimentation.

The system supports hologram recording using multiple recording media and provides a flexible optical setup for both educational and research applications. The adjustable optical arrangement and digital exposure control simplify operation while allowing users to gain practical experience in holographic recording and reconstruction techniques.

Experimental Principles & Applications

• Optical holography
• Interference and diffraction studies
• Hologram recording and reconstruction
• Three-dimensional image formation
• Optical information storage
• Wavefront recording techniques
• Coherent optics experiments
• Applied photonics investigations

• Physics laboratory experiments
• Holography education and training
• Optical imaging studies
• Interference and diffraction investigations
• Optical information storage demonstrations
• Photonics laboratory research
• Advanced optics experimentation

Laser Source :

• Semiconductor laser

Exposure Timer :

• Multiple operating modes
• Continuous exposure mode
• Timed exposure mode
• Manual exposure mode
• Digital display

Optical Components :

• Objective lens
• Beam splitter
• Plane mirror
• Supporting optical elements

Magnetic Mounting System :

• Universal magnetic base

Clamping & Adjustment System :

• Two-dimensional adjustment frame
• Laser holder
• Recording plate holder
• Lens holder
• Alignment accessories

Recording Media :

• Red-sensitive recording plate
• Holographic recording plate
• Multiple recording media options

Additional Components :

• Illumination meter
• Safety light
• Test targets
• Demonstration objects
• Supporting accessories

Vibration-Isolated Platform :

• Dimensions: 1200 × 800 × 200 mm
• Anti-vibration working platform
• Precision optical work surface
