Comprehensive Experiments on Rotating Liquid for Mechanics Physics Lab

This Comprehensive Experiments on Rotating Liquid for Mechanics Physics Lab is designed for investigating the mechanical and optical properties of rotating fluids. When a liquid rotates, its free surface naturally forms a parabolic shape, providing an effective platform for studying gravitational acceleration, rotational dynamics, and optical focusing phenomena. The apparatus integrates semiconductor laser measurement technology with precision rotational speed monitoring, enabling accurate analysis of both the geometric and optical characteristics of the rotating liquid surface. The parabolic liquid surface also functions as a concave reflector, allowing the study of imaging and focal length relationships within a single experimental system.

Manufactured by Atico Export India.

Experimental Principle and Content

• Measure Gravitational Acceleration Using the Height Difference of the Rotating Liquid Surface
• Determine Gravitational Acceleration Through Direct Surface Slope Measurements
• Study the Parabolic Surface Formed by a Rotating Liquid
• Verify the Relationship Between Focal Length and Rotational Period
• Investigate the Optical Focusing Properties of a Rotating Liquid Surface
• Study Concave Mirror Imaging Using the Rotating Liquid Surface
• Analyze the Influence of Rotational Speed on Optical Performance

Educational Objectives

• Understand the Mechanics of Rotating Fluids
• Explore Methods for Determining Gravitational Acceleration
• Study the Formation and Properties of Parabolic Surfaces
• Investigate the Relationship Between Rotational Motion and Optical Behavior
• Learn Experimental Techniques Involving Lasers and Precision Measurements
• Develop Practical Skills in Mechanics and Optics Experimentation

Semiconductor Lasers :

• Quantity: 2 pcs
• Output Power: 2 mW Each

Spot Laser Beam :

• Beam Diameter: Less Than 1 mm
• Adjustable Beam Size

Divergent Laser Beam :

• Included

Laser Mount :

• Two-Dimensional Adjustable Mount

Cylinder Container :

• Material: Transparent Plexiglass
• Height: 90 mm
• Inner Diameter: 140 ± 2 mm

Motor Drive System :

• Adjustable Rotational Speed
• Maximum Speed: Less Than 0.45 s/Turn

Speed Measurement System :

• Measuring Range: 0–9.999 s
• Accuracy: 0.001 s

Vertical Scale Ruler :

• Length: 490 mm
• Minimum Division: 1 mm

Horizontal Scale Ruler :

• Length: 220 mm
• Minimum Division: 1 mm

Standard Supply

• Main Electric Unit × 1
• Rotation Stage × 1
• Beam Assembly × 1
• Semiconductor Lasers × 2
• Two-Dimensional Adjustable Support × 1
• Observation Screen × 1
• Cylinder Container × 1
• Bubble Level × 1
• Power Cord × 1
• Instruction Manual × 1

• Well-Designed Experimental Structure
• Stable and Reliable Experimental Data
• Comprehensive Experimental Capabilities
• Suitable for Mechanics and Optics Studies
