ATENG 12925 — Comprehensive Gasoline Test and Diagnostic Bench for Combustion Engines with Fault Simulation
Anodized aluminum frame and panels made of painted steel.
The unit includes wheels to facilitate its mobility.
Main metallic elements made of stainless steel.
- Bench composed of the following elements: safety mushroom button, key, USB connector for
computer, hood opening, and plug.
Articulated and transparent hood with electric lock for full visualization of the complete system.
- High-strength aluminum chassis coated with epoxy paint, supported on 160 mm diameter wheels.
Auxiliary panel composed of all the auxiliary elements found in a vehicle.
Emergency mushroom button, lateral emergency button for engine detection. A safety mushroom
button is provided on each side of the unit.
Original vehicle fuel tank.
Electronic throttle with lock.
Liquid retention tank in case of leakage or improper handling.
- Battery box, includes 12 V car battery, battery cut-off relay for unit safety, and battery charger. ATENG 12925 detail
Fuse and relay box, main engine fuses, and relays.
Battery cut-off relay for unit safety.
- Gasoline engine block with all necessary elements involved in its proper operation: engine, injectors, coils, intake filter, intake manifold,
ECU, etc.
Diagnostic system displaying CAN network information on a high-resolution screen.
Fault generation module with 14 faults.
Terminal block with 12 electrical signals.
Cables and accessories, for normal operation.
