The jig assembly is used for uniaxial compressive strength tests of rock core specimens with °50 to 55 mm and 100 to 110 mm height.
The assembly is also used for compressive strength test of natural stone core specimens.
Compression Jig Assembly is used for uniaxial compressive strength test for rock core specimens.
Construction :
Consists of a two-column frame fit with an upper platen with spherical seat that moves vertically sustained by a spring. The lower platen is fitted to the base.
