Compression Testing Machine– Channel Type Load Frame Hand Operated

Usage :

• Suitable for Laboratory Experiment / Testing

Construction :

• Robust-Solid Metal Construction

Load Frames :

• Material : MS Channels, C Type, welded at top & bottom with stand high loads

Hydraulic Jack :

• Fitted at Centre of base of load frame, over which can be fitted lower platen and spacer block with the help of centering pin

Lead Screw :

• Provided, passes through top of frame, upper platen is fitted at lower end of screw

Platens :

• Material : Hardened Metal duly polished, accurately machined, Upper & Lower part (1 each)

Test Ranges :

• 50 kN to 1500 kN

Standards Compliance :

• IS 516, BS 1881
