Compression Testing Machine – Fully Automatic with Pace Rate Controller

Capacity :

• ATCE1205/A - 2000 kN
• ATCE1205/B - 3000 kN

Ram Diameter :

• ATCE1205/A - 215 mm
• ATCE1205/B - 260 mm

Least Count :

• 0.1 kN

Ram Travel :

• 60 mm

Lower Platens Dimensions :

• ATCE1205/A - 280 mm
• ATCE1205/B - 310 mm

Upper Platens Dimensions :

• ATCE1205/A - 280 mm
• ATCE1205/B - 310 mm

Max Vertical Clearance between Platens :

• ATCE1205/A - 320 mm
• ATCE1205/B - 350 mm

Horizontal Clearance :

• ATCE1205/A - 380 mm
• ATCE1205/B - 400 mm

Load Frame Height :

• 1200 mm

Specimen Size (Can be Tested)

• Cube :- 70.6, 100, 150, 200 mm
• Cylindrical :- 100, 150, 200, 300 mm

Motor Capacity :

• 1 HP

Standard Compliance :

• IS14858:2000

Power Supply :

• 220 VAC, 50 Hz, Single Phase
