Compression Testing Machine – Pillar Type Load Frame (Hand Operated)

Capacity :

• ATCE1190/A - 1000 KN
• ATCE1190/B - 1000 KN

Pressure Gauge :

• ATCE1190/A - 1000 KN
• ATCE1190/B - 1000 KN

Least Count :

• ATCE1190/A - 5 KN
• ATCE1190/B - 5 KN

Pressure Gauge Diameter :

• ATCE1190/A - 150 mm
• ATCE1190/B - 200 mm

Vertical Daylight :

• ATCE1190/A - 310 mm (Adj)
• ATCE1190/B - 310 mm

Horizontal Clearance :

• ATCE1190/A - 260 mm
• ATCE1190/B - 240 mm

Platen Size :

• ATCE1190/A - 240 x 165 mm
• ATCE1190/B - 220 mm

Ram Diameter :

• ATCE1190/A - 165 mm
• ATCE1190/B - 165 mm

Ram Travel :

• ATCE1190/A - 50 mm
• ATCE1190/B - 50 mm

Type of Loading Unit :

• ATCE1190/A - Channel Type
• ATCE1190/B - Four Pillar (Portable) Type

Specimen Size (Can be Tested)

Cube :

• ATCE1190/A - 100 x 150 mm
• ATCE1190/B - 100 x 150 mm

Cylindrical :

• ATCE1190/A - 100 x 200 mm & 150 x 300 mm
• ATCE1190/B - 100 x 200 mm & 150 x 300 mm

Brick :

• ATCE1190/A - 100 x 100 x 225 mm
• ATCE1190/B - ---------
