Compression Testing Machine (Semi–Automatic) Power Pack Type

Usage :

• Suitable for Concrete Laboratory Testing

Operation Mechanism :

• Motorized Device runs with help of power supply and manual regulation

Capacity :

• 2000 KN

Ram Dia. :

• 215 mm

Least Count :

• 0.1 kN

Ram Travel :

• 60 mm

Lower Platens Dimensions :

• 280 mm

Upper Platens Dimensions :

• 280 mm

Max. Vertical Clearance between Platens :

• 320 mm

Horizontal Clearance :

• 380 mm

Cube Mould Capacity :

• 70.6, 100, 150, 200 mm

Cylindrical MouldCapcity :

• 100, 150, 200, 300 mm

Pump Station :

• Duo-Speed Pump; helps the device to control over its compression and load application

Motor Capacity :

• 1 HP

Power Supply :

• 220 VAC, 50 Hz, Single Phase

Standard Compliance :

• IS14858 : 2000
