Compressive Load Frame oil and petroleum testing instruments by ATICO EXPORT

The automated compressive load frame was designed to determine the compressive strength of a well cement or proppant. The most common means of determining the compressive strength of a cement involves applying a force to the sample at a constant rate until the sample fails. The maximum loading at which the cement fails is defined as the cement's compressive strength.

Maximum press capacity :

• 40,000 lbf

Maximum pressure :

• 10,000 PSI (based on a 2” cement cube with surface area of 4 in2)

Minimum press threshold :

• 1,000 lbf

Minimum pressure :

• 250 PSI (based on a 2” cement cube with surface area of 4 in2)

Loading rates :

• variable from 250 to 40,000 lbf/min in increments of 250

Size :

• 23” W × 23” D × 26.5” H (58 × 58 × 67 cm)

Weight :

• 225 lb (102 kg)

Requirements :

• Power supply: 115 / 220 Volt, 50/60 Hz

• Compact footprint saves lab space and increases efficiency with quick and easy clean up
• Clamshell head design and safety switches protect people and equipment from possible debris during operation
• Safety head, rupture disk and high-pressure alarm assembly help prevent over pressure
• Self-aligning platens allow easier sample loading and equal force application
• Operates in standalone mode or with computer control via RS-232 or Ethernet connections
• Variable load rate and constant load testing

Data Acquisition Features:

• Tailored interface makes common actions easy to locate
• Tab and drop-down based software optimizes screen areas without sacrificing information display
• Capable of testing varying samples and displaying results on a real-time chart
• Records historical data for easy analysis
