Computer Controlled Thermal Conductivity of Building and Insulating Materials Unit Deluxe

The Computer Controlled Thermal Conductivity of Building and Insulating Materials Unit, is a unit employed to measure thermal conductivity of low-conductivity materials, such as insulating materials.

ATENG 12245 — Computer Controlled Thermal Conductivity of Building and Insulating Materials Unit

(for main items)

• With this unit there are several options and possibilities:
• Main items: 1, 2, 3, and 4.
• Optional items: 5, 6, 7 and 8.
• Let us describe first the main items (1 to 4):
• 1 ATENG 12245. Unit:
  Bench-top unit.
  Thermallly insulated unit.
• Plate temperature ranges: 0 – 40 °C.
• Plate temperature control: Peltier System.
• Cooling system: Forced Air.
• Specimens:
• L x W: 300 x 300 mm.
• Thickness: 5 – 100 mm.
  It is recommended to use fibrous, granular and cellular
  materials and soft, rigid and semi-rigid materials.
• Thermal resistance range: 0.1 – 8.0 m²·K/W.
• Thermal conductivity range: 0.002 – 1.0 W/m·K.
  Loading system ensures that the same force is applied to the
• specimens. Value: 21 KPa.
  Two heat flux sensors, situated in the cold and hot plate.
• Six temperature sensors, located in different points of the unit:
  Three sensors situated in the hot plate.
• Three sensors situated in the cold plate. Unit: ATENG 12245
• Repeatability: 0.5 %.
• Accuracy: ± 1 – 3%.
• Set of specimens:
• Materials: black nitrile rubber, polyacetal, expanded polystyrene, PTFE, PMMA, PVC, glass fiber and
  glass fiber with resin.
  The unit is connected with the computer via USB connection cable.
• The complete unit includes as well:
  Advanced Real-Time SCADA.
  Open Control + Multicontrol + Real-Time Control.
  Specialized Control Software based on LabVIEW.
  National Instruments Data Acquisition board (250 KS/s, kilo samples per second).
  Calibration exercises, which are included, teach the user how to calibrate a sensor and the
  importance of checking the accuracy of the sensors before taking measurements.
  Projector and/or electronic whiteboard compatibility allows the unit to be explained and
  demonstrated to an entire class at one time.
  Capable of doing applied research, real industrial simulation, training courses, etc.
  Remote operation and control by the user and remote control for technical support,
  are always included.
  Totally safe, utilizing 4 safety systems (Mechanical, Electrical, Electronic & Software).
  Designed and manufactured under several quality standards.
  Optional ICAI software to create, edit and carry out practical exercises, tests, exams,
  calculations, etc. Apart from monitoring user's knowledge and progress reached.
  This unit has been designed for future expansion and integration. A common expansion is
  the Scada-Net (ESN) System which enables multiple students to simultaneously
  operate many units in a network.
  3

Complete Technical Specifications (for main items)

• 2 TCMC/CCSOF. Computer Control + Data Acquisition + Data Management Software:
  The three softwares are part of the SCADA system.
  Compatible with actual Windows operating systems. Graphic and intuitive simulation of the process in
  screen. Compatible with the industry standards.
  Registration and visualization of all process variables in an automatic and simultaneous way.
  Flexible, open and multicontrol software, developed with actual windows graphic systems, acting
  simultaneously on all process parameters.
  Management, processing, comparison and storage of data.
  Sampling velocity up to 250 KS/s (kilo samples per second).
  Calibration system for the sensors involved in the process.
  It allows the registration of the alarms state and the graphic representation in real time.
  Comparative analysis of the obtained data, after the process and modification of the conditions during
  the process. TCMC/CCSOF
  Open software, allowing the teacher to modify texts, instructions. Teacher’s and student’s
  passwords to facilitate the teacher’s control on the student, and allowing the access to different work
  levels.
  This unit allows the 30 students of the classroom to visualize simultaneously all the results
  and the manipulation of the unit, during the process, by using a projector or an electronic
  whiteboard.
  3 Cables and Accessories, for normal operation.
• 4Manuals:
• This unit is supplied with 8 manuals: Required services, Assembly and Installation, Control software,
  Starting-up, Safety, Maintenance, Calibration & Practices manuals.
• References 1 to 4 are the main items: ATENG 12245 + TCMC/CCSOF + Cables and Accessories + Manuals are included in the minimum
  supply for enabling normal and full operation.
