Configurable Multi Unit Freezing, Cloud, Pour for Oil Fuel and Petroleum Testing Instruments

The Automated Petroleum Low-Temperature Property Analyzer determines the cloud point, pour point, cloud and pour points, cold filter plugging point (CFPP), and freezing point of petroleum products and aviation fuels. Cloud point testing identifies the temperature at which hydrocarbon crystals first become visible, while pour point testing determines the lowest temperature at which the sample continues to flow. CFPP testing estimates the lowest temperature at which diesel, biodiesel, and heating fuels can provide trouble-free flow through certain fuel systems. Freezing point testing identifies the temperature at which solid hydrocarbon crystals disappear during controlled warming. The system features an integrated panel PC with a 12-inch TFT/LCD touchscreen, automated testing software, and real-time data display and recording. Direct cooling eliminates the need for solvent cooling baths, with one-stage and two-stage cooling configurations available. Multiple configurations support two, three, four, or six test positions, with analytical heads selectable for different testing methods. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for petroleum and aviation fuel testing applications.

Temperature Range:

• One-stage cooling: +60°C to -45°C
• Two-stage cooling: +60°C to -80°C

Measurement Specifications:

• Resolution: 0.06°C
• Accuracy: ±0.1°C
• Repeatability and reproducibility: According to standard test methods or better
• Data storage capacity: Up to 60,000 analyses

Control and Software:

• Integrated panel PC with 12-inch TFT/LCD touchscreen
• Display resolution: 1024 × 768
• 16.2 million colors
• Real-time display and graphing of analytical parameters
• Microsoft Excel-compatible data files
• Monitoring of solenoid valves, cooling system, pressure sensors, and PT100 Class A temperature probe
• Automated testing and data recording

Cooling System:

• Direct cooling system without solvent cooling baths
• One-stage cooling configuration
• Two-stage cooling configuration
• CFC-free motor compressors
• Rapid cooling capability
• Consistent cooling profiles for repeatable and reproducible results

Cloud Point Detection:

• Automated optical detection using light scattering
• Light pulse emission at 1°C intervals
• Coaxial fiber-optic cable and optical sensor
• Detection of initial crystallization in clear and transparent oils

Pour Point Detection:

• Automated sample tilting at 3°C intervals
• 90° test jar tilting
• Two PT100 detection probes to identify sample flow
• Automatic return of the test jar to the cooling jacket
• No-flow detection for 5 seconds
• Pour point reported at 3°C above the temperature at which the sample ceases to flow

Freezing Point Detection:

• Automated optical detection of hydrocarbon crystallization
• Light pulse emission at 0.5°C intervals
• Coaxial fiber-optic cable, mirror, and optical sensor
• Controlled sample cooling with constant stirring
• Controlled warming to determine crystal disappearance temperature
• Suitable for clear and transparent fuels regardless of sample color

Cold Filter Plugging Point Detection:

• Automated cooling according to a selected temperature profile
• Vacuum pressure: 20 mbar
• Filtration through a 45-micron mesh filter
• Automatic detection based on sample passage time
• Test completion when sample passage or return takes more than 60 seconds

Available Configurations:

• Two test positions
• Three test positions
• Four test positions
• Six test positions
• Selectable analytical heads for cloud point, pour point, cloud and pour point, CFPP, and freezing point
