Constant Temperature Circulating Baths for Oil Fuel and Petroleum Testing Instruments

The Constant Temperature Circulating Bath provides precise temperature control for laboratory applications requiring stable heating and fluid circulation. Available in three reservoir capacities of 6, 13, and 28 liters, it features a large reservoir opening, microprocessor temperature control, and digital temperature setting and display in °C or °F. Adjustable over-temperature protection and low-liquid cut-off help ensure safe operation. The programmable model offers time and temperature programming, remote probe capability, and a variable-speed duplex pressure/suction pump. It includes an RS232 interface and PC programming software, with LabVIEW drivers and Excel macros available for enhanced programming and data logging. A graphic LCD and multilingual help menus simplify operation and setup. The standard model features three user-defined temperature setpoint buttons, a bright LED display, and a two-speed pressure pump suitable for closed-loop applications. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for laboratory temperature control applications.

Available Capacities:

• 6 liters
• 13 liters
• 28 liters

Temperature Control:

• Temperature readout: °C or °F
• Adjustable over-temperature protection
• Low-liquid cut-off

Programmable Model:

Temperature Stability:

• ±0.01°C

Readout Accuracy:

• ±0.25°C

Pressure Flow Rate:

• Maximum 30 L/min at 60 Hz
• Maximum 22 L/min at 50 Hz

Suction Flow Rate:

• Maximum 22 L/min at 60 Hz
• Maximum 15 L/min at 50 Hz

Heater Power:

• 1100 W at 60 Hz
• 2200 W at 50 Hz

Features:

• Time and temperature programming
• Remote probe capability
• Variable-speed duplex pressure/suction pump
• RS232 interface
• PC programming software
• LabVIEW drivers and Excel macros for programming and data logging
• Graphic LCD display
• Multilingual help menus

Standard Model:

Temperature Range:

• 5°C to 150°C

Temperature Stability:

• ±0.05°C

Readout Accuracy:

• ±0.5°C

Pressure Flow Rate:

• Two-speed pump: 9 or 15 L/min

Suction Flow Rate:

• Not available

Heater Power:

• 1100 W at 60 Hz
• 1600 W at 50 Hz

Features:

• Microprocessor temperature control
• Bright LED setpoint and temperature display
• Three user-defined temperature setpoint buttons
• Two-speed pressure pump for closed-loop applications
