Constant Temperature Hydrometer for Oil Fuel and Petroleum Testing Instruments

The Constant Temperature Hydrometer Bath is designed for determining the density, relative density (specific gravity), and API gravity of crude petroleum, liquid petroleum products, and mixtures of petroleum and non-petroleum products. It also supports Reid Vapor Pressure determinations using immersion bombs. Available in 6-position and 12-position models, the bath provides temperature control for petroleum product testing. Digital temperature control enables rapid temperature stabilization while minimizing overshoot. An over-temperature protection circuit interrupts power if the bath temperature exceeds the programmed cutoff point. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for petroleum density and gravity testing applications.

Available Models and Capacity:

• 12-position model: 12 hydrometers
• 6-position model: 6 hydrometers

Temperature Range:

• Ambient to 221°F (105°C)

Temperature Control:

• Digital temperature control
• Rapid temperature stabilization with minimal overshoot
• Temperature control stability exceeding ASTM requirements
• Over-temperature protection with programmable cutoff

Bath Medium and Capacity:

• 12-position model: 16.1 gallons (60.9 L) of white technical oil
• 6-position model: 9.9 gallons (37.5 L) of white technical oil
