Constant Temperature Water Bath for Oil Fuel and Petroleum Testing Instruments

The Constant Temperature Water Bath provides accurate temperature control, range, and uniformity for laboratory applications. It maintains bath temperatures up to 100°C with the cover installed and up to 60°C without the cover, with 0.1°C setpoint precision and ±0.2°C temperature uniformity. The bright LED display continuously indicates the bath temperature in Celsius or Fahrenheit. Three user-defined temperature preset buttons allow quick selection of frequently used settings. Dual thermostats provide redundant safety protection, while a high-limit alarm alerts the operator when the bath exceeds the preset temperature limit. A secondary safety thermostat automatically disconnects heater power if the temperature becomes too high or the liquid level drops too low. The steeply gabled polycarbonate cover accommodates glassware of varying heights and allows condensate to drain back into the bath. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for laboratory temperature control applications.

Temperature Control:

• Microprocessor-based temperature control
• Setpoint precision: 0.1°C
• Bright LED temperature display
• Selectable Celsius or Fahrenheit display
• Three user-defined temperature preset buttons
• Electronic calibration
• Front-panel lockout

Temperature Range:

• Ambient to 100°C with cover
• Ambient to 60°C without cover

Temperature Stability and Uniformity:

• Temperature uniformity: ±0.2°C

Safety Features:

• Dual thermostats
• Redundant safety backup
• High-limit temperature alarm
• Secondary safety thermostat
• Automatic heater power cutoff in over-temperature conditions
• Low-liquid-level protection

Construction and Features:

• Steeply gabled polycarbonate cover
• Accommodates glassware of varying heights
• Hinged cover design for convenient sample loading and removal
• Condensate drains back into the bath
