In the continuity equation, the relationship between the cross-sectional flow area and the flow velocity is analysed. These physical laws are the foundation of fluid mechanics.
Technical Specifications
visualisation of the flow velocity
different cross-sectional areas determine the ratio of the flow velocity
two impellers with the same pitch for observation and measurement of the different flow velocities
speed of the impellers measured via inductive speed sensor
flow rate in the pipe section can be adjusted via the base module
automatic identification of accessories via RFID technology
experiment execution and display of measured values via touch screen (HMI)
network capability: access to ongoing experiments and their results from up to 10 external workstations simultaneously via the local network
