CONTINUOUS AND INDETERMINATE BEAMS

Three piers measure vertical reaction forces via integral load cells, which connect directly to a digital interface (sold separately). Each pier accommodates simply supported or continuous beams, allowing rotation but no vertical movement during testing. Sinking supports can be studied using each pier's height adjustment system and integral dial gauge. Learn about CONTINUOUS AND INDETERMINATE BEAMS price for optimal educational outcomes.. A fourth pier clamps a cantilever or the fixed end of a beam. A double pulley assembly provides vertical loading. Learn about CONTINUOUS AND INDETERMINATE BEAMS for educational labs for optimal educational outcomes.. Point loads and uniformly distributed loads (UDL) can be applied using calibrated weights and hangers. Three test beams in steel, aluminium and brass are supplied, with deflections monitored using dial gauges on moveable stands. Learn about CONTINUOUS AND INDETERMINATE BEAMS exporters for optimal educational outcomes..

• Steel Beam: 25 × 5 × 1200 mm
• Aluminium Beam: 25.4 × 3.2 × 1200 mm
• Brass Beam: 19 × 3.2 × 1200 mm
• Digital Dial Gauge: 12.7 mm travel; 0.01 mm resolution
• Sinking support indicators: 0–10 mm; 0.01 mm resolution
• Weights set: 5 × 1 N, 10 × 2 N, 10 × 5 N, 5 × 10 N, 1 × 20 N
