The RT 580 facilitates practical learning in the control of three controlled variables which are commonplace in process engineering.
Technical Specifications
control of level, flow rate, temperature and cascade control
PLC: 3 integrated controllers, monitoring of safety devices, 7 simulated faults; plant control and configuration via touch screen
integrated router for operation and control via an end device and for screen mirroring: mirroring of the user interface on up to 5 end devices
main circuit with collecting tank, graduated stirred tank with heater, pneumatic control valve and centrifugal pump
cool. circuit: pump, heat exchanger, rotameter
refr. system+pump to cool water in collecting tank
pneumatic control valve in main circuit as actuator for all controls
sensors for the measurement of the controlled variables; level, flow rate and temperature
data acquisition via PLC on internal memory, access to stored measured values via WLAN/LAN with integrated router/LAN connection to customer–s own network or direct LAN connection without customer network
software for data acquisition via LAN under Windows 11
