Copper Strip Corrosion from Lubricating Grease for Petroleum Testing Equipment

The Copper Strip Corrosion Test Bath for Lubricating Grease is designed to determine the tendency of lubricating grease to corrode copper under static conditions. A polished copper strip is immersed in a grease sample maintained at an elevated temperature for a specified period. After testing, the strip is examined for corrosion and assigned a classification number from 1 to 4 by comparison with the ASTM Copper Strip Corrosion Standards.

The apparatus features an immersion-type circulating water bath that maintains the test jars at the required depth and temperature. Its fully insulated, double-wall stainless steel construction supports consistent temperature control during testing.

Manufactured by Atico Export for reliable copper corrosion testing of lubricating greases and oils in petroleum testing laboratories.

• Determination of copper corrosion caused by lubricating grease
• Copper strip corrosion testing of lubricating oils
• Evaluation of lubricant corrosivity under static conditions
• Quality control and laboratory assessment of lubricants

Capacity :

• Accommodates 20 copper strip corrosion test tubes or jars, depending on the test configuration

Temperature Range :

• Ambient to 105°C (221°F)

Temperature Control Stability :

• Exceeds applicable ASTM requirements

Bath Medium and Capacity :

• Water bath capacity: 27.2 L (7.2 gallons)

Electrical Requirements :

• 115 V, 60 Hz, single phase, 10 A
• 220–240 V, 50/60 Hz, single phase, 5 A

Standard Test Procedure :

• A polished copper strip is immersed in the grease sample at the specified temperature and duration.
• The tested strip is compared with ASTM Copper Strip Corrosion Standards.
• Classification is assigned on a scale from 1 to 4.

Optional Accessories :

• Removable rack for compatible bath conversion
• Top cover plate
• Copper test strips, 12.5 × 1.5–3.0 × 75 mm, conforming to ASTM specifications
• Test jar
• Viewing test tube for copper strip inspection and storage

• Immersion-type circulating water bath
• Designed for copper strip corrosion testing of lubricating greases and oils
• Fully insulated, double-wall stainless steel construction
• Temperature range from ambient to 105°C
• Temperature control stability exceeding applicable ASTM requirements
• Compatible with test jars and copper strip testing accessories
• Overtemperature protection for safe operation
