Copper Strip Corrosion Pressure Vessel Bath for Petroleum Testing Equipment

The Copper Strip Corrosion Test Bath is designed to evaluate the relative corrosivity of petroleum products, including aviation fuels, automotive gasoline, natural gasoline, solvents, kerosene, diesel fuel, distillate fuel oil, lubricating oils, and other petroleum products.

During testing, a polished copper strip is immersed in 30 mL of the sample and maintained at a specified temperature for a defined period. After testing, the strip is examined for tarnishing and corrosion and classified from 1 to 4 by comparison with the ASTM Copper Strip Corrosion Standards.

For aviation fuels and natural gasoline, the sample tube is placed inside a stainless steel pressure vessel during testing. The equipment is available in four-position and eight-position bomb bath models, as well as a 20-position test tube bath model for products that do not require a pressure vessel.

Manufactured by Atico Export for reliable corrosion testing and quality evaluation of petroleum products.

• Copper strip corrosion testing of aviation gasoline and aviation turbine fuels
• Testing of automotive gasoline and natural gasoline
• Evaluation of kerosene, diesel fuel, and distillate fuel oils
• Corrosion testing of lubricating oils and solvents
• Assessment of petroleum product corrosivity
• Quality control according to ASTM and related specifications

Available Models and Capacity :

• Four-position model: Holds 4 copper strip corrosion test bombs
• Eight-position model: Holds 8 copper strip corrosion test bombs
• Test tube bath model: Holds 20 copper strip corrosion test tubes

Temperature Range :

• Ambient to 105°C (221°F)

Temperature Control Stability :

Bath Medium and Capacity :

• Four-bomb bath: 23.1 L (6.1 gallons) of water
• Eight-bomb bath: 27.2 L (7.2 gallons) of water
• 20-position test tube bath: 27.2 L (7.2 gallons) of water

Power Supply :

• 115 V, 60 Hz, single phase, 10 A
• 220–240 V, 50/60 Hz, single phase, 5 A

Standard Test Procedure :

• Sample volume: 30 mL
• Corrosion classification: 1 to 4, based on comparison with ASTM Copper Strip Corrosion Standards

• Available in four-bomb and eight-bomb bath models
• 20-position test tube bath model available
• Temperature-controlled water bath for consistent testing
• Fully insulated construction
• Double-wall stainless steel construction for bomb bath models
• Stainless steel inner wall and powder-coated steel outer wall for test tube bath models
• Built-in support rack for test tubes
• Overtemperature protection that automatically interrupts power when the programmed temperature limit is exceeded
• Optional removable rack for converting the compatible bath for alternative test configurations
