ATENG 12097 — Coriolis Force Demonstration Unit
Bench-top unit.
Anodized aluminum frame and panels made of painted steel.
Main metallic elements made of stainless steel.
Diagram in the front panel with distribution of the elements similar to the real one.
- Transparent water tank. It Includes:
Scale to read the deflection of the water jet.
Purge valve.
Measuring rod for an easy measurement of the jet deflection.
- Submersible pump. Range: 0 – 10 l/min. Operation range: 0 – 5 l/min.
- Motor with speed control. Speed range: 0 – 60 rpm.
Rotating arm with counterweight to ensure a smooth and steady rotation at high speeds.
Safety device to disconnect the unit when opening the protection cover. ATENG 12097 detail
- Electronic console:
Metallic box.
Main switch.
Pump switch.
Motor switch.
Switch to select the direction of rotation.
Motor speed controller.
Flow rate controller for the pump.
Digital display for the motor speed.
Digital display for pump flow rate.
Cables and accessories, for normal operation.
