Coupling Coefficient of Piezoelectric Crystal for Physics Lab

Designed to determine the coupling coefficient of a piezoelectric crystal.

Physics Lab Experiments Setup from Atico Exports.

Piezoelectric Crystals :

• 5 Crystals of Standard Values Mounted Inside the Box
• Connections Provided on Terminals at the Top of the Panel

Resistance Box :

• 10 Resistors Connected Inside the Box

Inductance Box :

• 10 Inductors Connected Inside the Box

Capacitance Box :

• 10 Capacitors Connected Inside the Box

Measuring Instruments :

• AC Voltmeter
• AC Current Meter

Function Generator :

• 2 MHz

Additional Components :

• Connecting Leads
