Coupling Coefficient of Piezoelectric Crystal for Physics Lab Experiments Complete Set

To determine the coupling coefficient of a piezoelectric crystal. Physics Lab Experiments Setup from Atico Exports.

Apparatus Used :

• Piezoelectric Crystals with standard values, mounted inside the panel with connections brought to the terminals
• Resistance Box with multiple resistance values
• Inductance Box with multiple inductance values
• Capacitance Box with multiple capacitance values
• AC Voltmeter
• AC Current Meter
• Function Generator, 2 MHz
• Connecting Leads
