Crank mechanism kit

Crank drives are frequently used in compressors and pumps. They cause vibration due to the oscillating masses and forces. Under the alternating stress in the drive mechanism, bearing clearance, for example, can generate shock impacts with high-frequency exciter spectra. Learn about Crank mechanism kit specifications for optimal educational outcomes.. In addition, free mass forces generate harmonic vibrations due to their non-linear kinematics.

• investigation of the vibrations of crank drives
• experiment carried out in conjunction with the training system and measurement and evaluation tools
• belt drive or gear unit required for experiment with gas forces
• crank drive with adjustable stroke
• interchangeable bearing bushes permit simulation of bearing clearance
• springs simulate gas forces
• can be used together with gear damage accessory set
• stackable storage system to house the components
