CURING TANK – HEAVY PLASTIC

Standards Compliance :

• Complied as per EN 12390-2, ASTM C31, C192, C511

Application :

• Curing tanks are designed for curing concrete cubes and cylinders.
• Temperature is adjusted by analog or digital thermostat, maintaining ambient to 40 °C °2 °C.

Standard Supply :

Supplied complete with :

• Analog or digital thermostat-controlled heater
• Base metal rack
• Submersible circulation pump
• Cover

Optional Accessories :

• Tong for cube mould should be ordered separately.

Internal Dimensions (cm) :

• AECE2078/A - 92 ° 111 ° 61
• AECE2078/B - 74 ° 112 ° 65
• AECE2078/C - 92 ° 111 ° 61
• AECE2078/D - 74 ° 112 ° 65

External Dimensions (cm) :

• AECE2078/A - 104 ° 124 ° 80
• AECE2078/B - 84 ° 124 ° 84
• AECE2078/C - 104 ° 124 ° 80
• AECE2078/D - 84 ° 124 ° 84

Weight (kg) :

• AECE2078/A - 30
• AECE2078/B - 25
• AECE2078/C - 30
• AECE2078/D - 25
