Cutting Mill (Net weight - 160 kg)

The Cutting Mill (Net weight - 160 kg) excels especially in the tough jobs where other cutting mills fail. This mill allows for perfect adaptation to application requirements by variable speed from 100 to 3,000 min-1. A range of bottom sieves with aperture sizes from 0.25 - 20 mm is available, ensuring a defined final fineness.
The Cutting Mill (Net weight - 160 kg) delivers perfect results even for the most demanding grinding tasks

Functional Principle

Size reduction in the Cutting Mill (Net weight - 160 kg) takes place by cutting and shearing forces. The sample comes into contact with the rotor, and is comminuted between the blades and the stationary double acting cutting bars inserted in the housing.

Applications :

• size reduction by cutting

Field of application :

• agriculture, biology, chemistry / plastics, engineering / electronics, environment / recycling, food, medicine / pharmaceuticals

Feed material :

• soft, medium-hard, tough, elastic, fibrous

Size reduction principle :

• shearing, cutting

Material feed size :

• < 60 x 80 mm

Final fineness :

• 0.25 - 20 mm

Speed at 50 Hz (60 Hz) :

• 100 - 3000 min-1

Rotor peripheral speed :

• 4.7 - 20.3 m/s

Rotor diameter :

• 129.5 mm

Types of rotors :

• parallel section rotor / 6-disc rotor / V-rotor

Types of hoppers :

• universal, long stock

Material of grinding tools :

• stainless steel, steel for heavy-metal free grinding, tungsten carbide

Sieve sizes :

• trapezoid holes 0.25 / 0.50 / 0.75 / 1.00 / 1.50 mm
• square holes 2.00 / 4.00 / 6.00 / 8.00 / 10.00 / 20.00 mm

Collector systems / capacities :

• collecting receptacle 5 l / optional: 30 l
• collecting unit 0.25 / 0.5 l

cyclone-suction :

• combination (0.25 l - 30 l)

Drive :

• 3-phase asynchronous motor with frequency converter

Drive power :

• 3 kW with flywheel mass~ 28.5 kg

Electrical supply data :

• different voltages

Power connection :

• 1-phase

Engine brake :

• yes

Protection code :

• IP 20

W x H x D closed :

• 576 (1080 opened) x 1677 x 750 mm (with base frame and universal hopper)

Net weight :

• ~ 160 kg

Standards :

• CE
