Cutting Mill (Net weight - 73 kg without hopper, rotor and base frame)

The CUTTING MILL (NET WEIGHT – 73 KG WITHOUT HOPPER, ROTOR AND BASE FRAME) is the budget-priced basic model among the cutting mills. It is suitable for the size reduction of samples which don–t require extremely high forces. The mill has been specially designed for routine applications. It is easy to operate and can be mounted on a solid table or on the optional base frame.

Functional Principle

• Size reduction in the Cutting Mill (Net weight – 73 kg without hopper, rotor and base frame) takes place by cutting and shearing forces.
• The sample comes into contact with the rotor and is comminuted between the blades and the stationary standard cutting bars inserted in the housing.
• In the 6-disc rotor, spirally arranged reversible hard metal plates operate by cutting in sequence. The knives of the parallel section rotor carry out comminution with a powerful cutting action.
• The dwelling time of the sample in the chamber is short; as soon as it is small enough to pass through the openings of the bottom sieve it is discharged through the gravity outlet and collected in the receptacle.
• The rotor speed of 1,500 min–° ensures gentle and rapid size reduction.

Applications :

• size reduction by cutting

Field of application :

• agriculture, biology, chemistry / plastics, engineering / electronics, environment / recycling, food, medicine / pharmaceuticals

Feed material :

• soft, medium-hard, elastic, fibrous

Size reduction principle :

• shearing, cutting

Material feed size :

• < 60 x 80 mm

Final fineness :

• 0.25 - 20 mm

Speed at 50 Hz (60 Hz) :

• 1,500 min-1

Rotor peripheral speed :

• 9.4 - 11.4 m/s

Rotor diameter :

• 129.5 mm

Types of rotors :

• parallel section rotor / 6-disc rotor

Types of hoppers :

• standard, long stock

Material of grinding tools :

• stainless steel, steel for heavy-metal free grinding, tungsten carbide

Sieve sizes :

• trapezoid holes 0.25 / 0.50 / 0.75 / 1.00 / 1.50 mm
• square holes 2.00 / 4.00 / 6.00 / 8.00 / 10.00 / 20.00 mm

Collector systems / capacities :

• collecting receptacle 5 l / optional: 30 l
• collecting unit 0.25 / 0.5 l

Drive :

• 3-phase motor

Drive power :

• 1,5 kW

Electrical supply data :

• different voltages

Power connection :

• 3-phase

Protection code :

• IP 54

W x H x D closed :

• 582 x 1675 x 700 mm (with base frame and standard hopper)

Net weight :

• ~ 73 kg without hopper, rotor and base frame

Standards :

• CE

• For routine applications
• Feed size < 60 ° 80 mm
• Defined final fineness due to bottom sieves with aperture sizes from 0.25 – 20 mm
• Quick and easy cleaning due to smooth surfaces and push-fit rotor
• Gravity outlet for collection vessels of different sizes
• Wide range of accessories including various hoppers, collection systems, rotors and sieves
• Highest safety standards
