Cutting Mill (Net weight - 80 kg)

The Cutting Mill (Net Weight – 80 kg) revolutionizes laboratory workflows and solves multiple problems at the same time. With its innovative design featuring a removable milling chamber, the CUTTING MILL (NET WEIGHT – 80 KG) simplifies cleaning, saving up to 30 % process time.
At the same time, the unrivaled powerful benchtop cutting mill with a single phase power plug allows up to 100 % sample recovery and contamination-free sample preparation.

Technical Highlights :

• 1.5 kW drive with variable speed
• Speed range: 500 – 4,000 rpm
• Maximum speed: 4,000 rpm
• 130 mm rotor diameter
• 48 mm rotor depth
• Cutting speed: 27 m/s
• 3 double-acting cutting bars
• 18 cutting events per rotation
• Specific cutting length: 864 mm per rotation
• Optimized design for reduced blockages
• Pivoting handle with comprehensive door opening mechanism

Functional Principle :

• The Cutting Mill (Net Weight – 80 kg) utilizes cutting and shearing forces for size reduction.
• Samples are fed in batches through the Easy Inspect hopper and transported to the milling chamber using a plunger. Inside the chamber, comminution takes place between rotor blades and stationary double-acting cutting bars.
• The 3-disc rotor is equipped with spirally arranged reversible hard metal plates that cut sequentially, while the parallel section rotor delivers strong cutting action for efficient comminution.
• Cyclone technology transfers material from the milling chamber to the receptacle. Air vents optimize sample discharge and improve separation efficiency.
• With its variable speed range from 500 to 4,000 rpm, the CUTTING MILL (NET WEIGHT – 80 KG) can be precisely adapted to different application requirements.

Applications :

• size reduction by cutting

Field of application :

• agriculture, chemicals / plastics, construction materials, electronics, environmental / recyling, food / feed, pharma / biotech / medtech, power generation / energy

Feed material :

• soft, medium-hard, tough, elastic, fibrous

Size reduction :

• principle shearing, cutting

Material feed size :

• 50 mm

Final fineness :

• 0.25 - 10 mm

Speed at 50 Hz (60 Hz) :

• 500 - 4,000 min-1

Rotor peripheral speed :

• 4.3 - 27.1 m/s

Rotor diameter :

• 129.5 mm

Types of rotors :

• parallel section rotor / 3-disc rotor

Types of hoppers :

• EasyInspect hopper

Material of grinding tools :

• stainless steel, steel for heavy-metal free grinding

Sieve sizes :

• trapezoid holes 0.25 / 0.50 / 0.75 / 1.00 mm
• square holes 2.00 / 4.00 / 6.00 / 8.00 / 10.00 mm

Collector systems / capacities :

• collecting glass 0.25 / 0.5 l (not for gravity chamber) and collecting receptacle 3 l

Drive :

• 3-phase asynchronous motor with frequency converter

Drive power :

• 1.5 kW

Electrical supply data :

• 100 V, 110 V, 120 V, 20 A
• 200-230 V, 10 A

Power connection :

• 1-phase

Engine brake :

• yes

Protection code :

• IP 20

W x H x D closed :

• 565 x 750 x 530 (with base frame and hopper)

Net weight :

• 80 kg

Standards :

• CE
